ATN Fusion Image Intensification Thermal System FIITS14

The ATN Fusion Image Intensification Thermal System FIITS14 was developed in order to function as the best product for anybody trying to find a high quality option. These Night Vision Googles from the expert product professionals at ATN are fashioned by using heavy duty and reliable materials, as a way to provide you with a product that will be effective for many years. ATN has been devoted to providing quality goods for many years, and the ATN Fusion Image Intensification Thermal System FIITS14 is the verification of that dedication to their customer base. Right here at Night-Optics, we make it our personal task to ensure that you leave with the most suitable item for all of your expectations, and the ATN Fusion Image Intensification Thermal System FIITS14 is one of the numerous products which we have been extremely pleased to offer our clientele. And furthermore, as we won't charge for delivery on orders placed of $49 or higher, there may not be a more suitable time to choose the extraordinary ATN Fusion Image Intensification Thermal System FIITS14. For an impressive solution to make sure you are utilizing some of the best which the community is offering, choose the ATN Fusion Image Intensification Thermal System FIITS14.

The ATN Fusion Image Intensification Thermal System FIITS14 combines image intensification and infrared thermal imaging technologies for night time low light and adverse weather conditions observation. This is achieved by combining an advanced image intensification system with a thermal imaging system. The combination of the channels in these ATN Thermal Image Devices allows the user to take full advantage of both technologies by dichoptically creating a "Fused" image for enhanced night vision observation. The results of the ATN Fusion Image Intensification Thermal System is a fused image that allows you the benefits and capabilities of both technologies. You will be able to detect both the image intensified night vision scene and the thermal imaging scene so you will not miss anything that you would have been unable to see by either technology separately. The ATN FIITS14 Fusion Image Intensification Thermal System is lightweight, portable, and can be used as a handheld binocular or a dual eye goggle. The separate channels can be disengaged from one another and used individually as either a Night Vision or Thermal imaging monocular.

Specifications for ATN FIITS14 Fusion Image Intensification Thermal System:

Thermal Channel:
Magnification:		1X
Objective Focal Length:		16 mm
FOV:		11 x 8
Focus Range:		1m to infinity
Focus Adjustment:		Manual
Exit Pupil:		14mm
Eye Relief:		25mm
Detector Type:		Uncooled Microbolometer
Spectral Response:		7-14 µm
Pixels:		160 x 120
Pixel Size:		30 x 30 µm
Angular Resolution, mrad:		1,2
Thermal Sensitivity:		< 0,1C
Range to Detect a Human:		475 m
Output Format:		Analog PAL / NTSC
Display:		OLED matrix
Display:		Format SVGA, 852 x 600 pxl
Color:		Monochrome
Digital ZOOM:		Fixed 2x (optional 5x)
Brightness Adjustment:		Manual
Contrast Adjustment:		Automatic
Available User Interfaces:		From outside PC through USB interface
Power Supply:		2 x 3V, 123A type
Start-Up Time:		< 3 sec
Battery Life with One battery pack:		4 hrs
Battery Life with External Power Supply:		DC 6V, 500 mA
Operation Temperature:		from -20 C to +50 C
Waterproof:		Yes, up to 10m submersion
Dimensions:		118 x 78 x 54 mm
Weight (w/batteries):		0,34 kg
Night Vision Channel:
Magnification:		1X
Focus Range:		0.25 m to Infinity
Eye Relief:		25 mm
Exit Pupil:		14 mm
Dioptre Adjustment:		+- 4
Operation Temperature:		-40 To +50C
Storage Temperature:		-50 To +70C
Waterproof:		Yes, 20 m for 1 h
Power Supply:		one 3V, 123Atype
Battery Life:		25 hours (AA, 1.5 V); 50 hours (Lithium, 123a, 3v)
Dimensions:		125 X 49 X 69 mm
Weight (With Battery):		0.32 kg

Features of ATN Fusion Image Intensification Thermal System FIITS 14:

• Hand held or head/helmet mountable
• Images from NV or TI channels can be used separately or dichoptically fused
• TI channel "video-out" feature can be used with optional USB adapter and software which allows to display thermal images on computer or use them for further transmission
• High Quality optics
• FIITS14 can be attached to the optional head gear/helmet mount for "hands free" operations
• Video/Image polarity selection, white-hot or black-hot for thermal image
• Waterproof
• One Year Warranty

Package Contents:

• ATN Fusion Image Intensification Thermal System FIITS-14
• Warranty card
• Soft carrying Case
• Packing box
• Instruction Manual and CD guide
